Is there a DIY version of a CG checker?
#1
Senior Member
Thread Starter
My Feedback: (1)
Join Date: Sep 2003
Location: Downingtown,
PA
Posts: 321
Likes: 0
Received 0 Likes
on
0 Posts
Is there a DIY version of a CG checker?
Is there a DIY version of a CG checker that I can make? Are there any plans? Is it easy to build from home depot parts?
#4
Senior Member
Join Date: Apr 2002
Location: Laurel, MD,
Posts: 4,987
Likes: 0
Received 0 Likes
on
0 Posts
RE: Is there a DIY version of a CG checker?
I do most CG stuff with the fingers as well.
However, if you want an easy "machine" it's very simple. I have a bit of scrap wood that I drilled a few holes in. I put a wood dowl in the hole, and one of those penncil eraser caps on the top of the dowel. For heavy planes, I clamp the board to the work bench first. The only problem with this approach is that very heavy planes might damage themselves by sitting on the eraser ends, too much weight on such a small area, but I've used it on planes up to 14lbs with out issue.
However, if you want an easy "machine" it's very simple. I have a bit of scrap wood that I drilled a few holes in. I put a wood dowl in the hole, and one of those penncil eraser caps on the top of the dowel. For heavy planes, I clamp the board to the work bench first. The only problem with this approach is that very heavy planes might damage themselves by sitting on the eraser ends, too much weight on such a small area, but I've used it on planes up to 14lbs with out issue.
#6
RE: Is there a DIY version of a CG checker?
At one point I made REALLY fancy ones with two #2 pencils with big add-on erasers and paper clips bent into "L" shapes. I adjust the "L" in the eraser so I have the distance specified from the leading edge and add weights until it balances.
Normally masking tape on the desired balance points and fingertips. No matter WHAT the plans say I fly it to determine where the COG needs to be. The initial balance is just so it survives the maiden and first few trim flights.
Normally masking tape on the desired balance points and fingertips. No matter WHAT the plans say I fly it to determine where the COG needs to be. The initial balance is just so it survives the maiden and first few trim flights.
#7
Senior Member
Join Date: Feb 2006
Location: Poland,
OH
Posts: 3,204
Likes: 0
Received 0 Likes
on
0 Posts
RE: Is there a DIY version of a CG checker?
One of the older members at my club screws a small eyehook into the centerline of the wing at the recommended CG.
Seems like a good idea and any time he makes a change he can quickly check.
Seems like a good idea and any time he makes a change he can quickly check.
#8
Senior Member
My Feedback: (4)
RE: Is there a DIY version of a CG checker?
ORIGINAL: Charlie P.
No matter WHAT the plans say, I fly it to determine where the COG needs to be.
The initial balance is just so it survives the maiden and first few trim flights.
No matter WHAT the plans say, I fly it to determine where the COG needs to be.
The initial balance is just so it survives the maiden and first few trim flights.
A machine for balancing is about as necessary as a plastic rubber band puller (Yes, you can buy one of those)
The "Recommended CG" is just a "Ball Park" starting point. Balance it with your fingers, then fly it and determine if and where you want to adjust it to.
#10
RE: Is there a DIY version of a CG checker?
Unless your balancing heavy planes your fingers will do just fine. I used my fingers up untill I got into gassers. Then I use the hanging method (linked below).
http://www.rcuniverse.com/forum/m_708060/tm.htm
Austin
http://www.rcuniverse.com/forum/m_708060/tm.htm
Austin
#12
Senior Member
RE: Is there a DIY version of a CG checker?
The method mentioned above by using a cup hook at CG point from info plane kit are arf, really works best as you can also balance wings tip to tip when hanging plane. I built an 12 ft wing span Decathlon and I balanced it using top of wing as balance point. When we flew it i was tail heavy. Turned plane upside down and transfered CG piont to bottom of plane , reblanced it , and it took almost 4oz of lead to make it blanced right. We flew plane and it flew great.
#13
Senior Member
Join Date: May 2007
Location: cando,
MO
Posts: 926
Likes: 0
Received 0 Likes
on
0 Posts
RE: Is there a DIY version of a CG checker?
The last plane I balanced on a balance Machine (better cause it cost more than the pencils lol)
anyway upside down just like your supposed to and did not think i would get it back on the ground. Got it down and used my fingers and got it almost perfect. Move the batt. 1/2" and wala had it. The balancer had me way off or the recommended CG was wrong.
anyway upside down just like your supposed to and did not think i would get it back on the ground. Got it down and used my fingers and got it almost perfect. Move the batt. 1/2" and wala had it. The balancer had me way off or the recommended CG was wrong.
#15
Senior Member
Join Date: Mar 2007
Location: Chesnee,
SC
Posts: 511
Likes: 0
Received 0 Likes
on
0 Posts
RE: Is there a DIY version of a CG checker?
I wish I had a picture of it now, but I made a really cool CG checker out of 3/4 PVC.
The base was about 24" wide (across the wings) and 10" deep (nose to tail). On the sides of the base I put a T and some 16" verticals with a end cap. The plane's wing sits on the cap. When your all done If you don't glue the vertical's T will fold into a nice flat thing that you can stick anywhere.
Cost was like ummm $4
P.S.
Use the round PVC caps, not the square ones.
The base was about 24" wide (across the wings) and 10" deep (nose to tail). On the sides of the base I put a T and some 16" verticals with a end cap. The plane's wing sits on the cap. When your all done If you don't glue the vertical's T will fold into a nice flat thing that you can stick anywhere.
Cost was like ummm $4
P.S.
Use the round PVC caps, not the square ones.
#17
Senior Member
My Feedback: (47)
RE: Is there a DIY version of a CG checker?
Check out this Tinker Toy Balancer
http://webpages.charter.net/rcfu/Con.../BJConstr.html
Seems to fit your description and it looks simple and effective.
http://webpages.charter.net/rcfu/Con.../BJConstr.html
Seems to fit your description and it looks simple and effective.
#18
Senior Member
Join Date: May 2007
Location: cando,
MO
Posts: 926
Likes: 0
Received 0 Likes
on
0 Posts
RE: Is there a DIY version of a CG checker?
My plane holder while i am working on them is a work table from craftsmen that screws in and out (gets wider and narrower) and is about 2ft. long. I drilled 2 holes on each end and set pvc T's in them. Then ran 1ft. pieces stright up and put another T 3/4" put 1/2" thru T's for planes to sit on and about 4" pieces of 3/4 up again to hold them. I can just move the wings up and let them set on the 4" pieces and the pipe in the rear will keep the plane from falling in the rear and then you can pretty much balance with no fear of the plane falling. You can screw the table in and out and the 1/2" just slide thru the 3/4 T's without having to hold the plane. Works great. I still was using a CG machine but won't bother with the hard to use little thing anymore lol.
#19
Senior Member
Join Date: Jan 2007
Location: Tracy,
CA
Posts: 529
Likes: 0
Received 0 Likes
on
0 Posts
RE: Is there a DIY version of a CG checker?
I don't know how to link to it, but here's a jpg drawing of mine, in my photo gallery:
http://www.rcuniverse.com/gallery/ga...emberID=319717
http://www.rcuniverse.com/gallery/ga...emberID=319717
#20
Senior Member
RE: Is there a DIY version of a CG checker?
ORIGINAL: Bad_Daddy
I don't know how to link to it, but here's a jpg drawing of mine, in my photo gallery:
I don't know how to link to it, but here's a jpg drawing of mine, in my photo gallery:
If you click either, you get a response box that has a "Click here to upload images and files" option just to the bottom left of the text box. Click on it and it works just like the photo gallery did.
Hope to see your pictures in your posts soon...........
