Over the last couple of days I've completed the wing LE and TE sheeting. Took a while to do. I basically glue a section, clamp it and come back a couple hours later and do another section. I dragged the process out over several days.... glue/clamp, glue/clamp, rinse and repeat etc, etc.

A while back I bought a bunch of clamps at Harbor Freight for about 2$ a piece. You cant go wrong with these since similar clamps sell for 15-20$ Just wish I had bought more.

Next step is to install the tip tank mounting structure within the last rib bay then sheet the last bay at the tip
