Default Building a Super Scout with Pulse Jet

Well now I done it.
I spent most of last year getting the AMA to change the pulse jet rules.
Now that the rules have been changed to allow modern pulse jets, I had to get my order in.
I just got off the phone with Hubert.
I have ordered a Super Scout and a 100mm Pulse Jet.
Once the waiting game is done for it to show up here, this will be the build thread.

I hate waiting for new toys to show up.........
flyinfool1 is offline
Reply With Quote
Old 03-07-2015, 04:36 PM
  #2
flyinfool1
Thread Starter
My Feedback: (2)

flyinfool1's Avatar

Join Date: Jan 2002
Location: Cudahy, WI
Posts: 831
Gallery
My Gallery
Models
My Models
Ratings
My Feedback
Default

This should be fun.

Attached Thumbnails Click image for larger version

Name:	Pulso1.jpg
Views:	668
Size:	25.9 KB
ID:	2079585   Click image for larger version

Name:	SS_1.jpg
Views:	695
Size:	63.1 KB
ID:	2079586   Click image for larger version

Name:	SS_2.jpg
Views:	650
Size:	41.5 KB
ID:	2079587
flyinfool1 is offline
Reply With Quote
Old 03-15-2015, 09:16 AM
  #3
flyinfool1
Thread Starter
My Feedback: (2)

flyinfool1's Avatar

Join Date: Jan 2002
Location: Cudahy, WI
Posts: 831
Gallery
My Gallery
Models
My Models
Ratings
My Feedback
Default

It is in the box ready to start its swim across the Atlantic.

The box is 155cm x 115cm x 20cm. Thats 61" x 45" x 8"

Did I mention I hate waiting for toys........

Attached Thumbnails Click image for larger version

Name:	20150315_101405_resized.jpg
Views:	623
Size:	213.2 KB
ID:	2081679

Last edited by flyinfool1; 03-15-2015 at 09:21 AM.
flyinfool1 is offline
Reply With Quote
Old 03-19-2015, 12:28 PM
  #4
flyinfool1
Thread Starter
My Feedback: (2)

flyinfool1's Avatar

Join Date: Jan 2002
Location: Cudahy, WI
Posts: 831
Gallery
My Gallery
Models
My Models
Ratings
My Feedback
Default

WOW!!!

I can't help but to say something, this just has me totally amazed.

Tuesday March 17 at 10:27 am I made an internet purchase from Germany.
The box to ship this was 4 feet x 5 feet x 8 inches, and weighed about 28 lbs.
It was picked up at the sellers house by DHL International Express on Tuesday at 13:41 on 3-17-15.
It was delivered to me today at 14:27 on 3-19-15.

This just blows my mind that a big package can get from Germany to Wisconsin, with customs thrown in, in just 50 hours, 46 minutes.

I mailed a USPS small flat rate box to travel just 90 miles and it took 5 days to get there.

My hat is off to DHL for whatever they are doing, they are doing it right.

In all fairness I must admit that when the tracking first came up on line a few minutes after the package pickup. I laughed that it said the expected delivery was by the end of the day on 3-19-15. I figured no way in he11.

I had this delivered to my work so that it would not be sitting in front of my house looking like a big flat screen TV.

Now I am chomping at the bit to get home to open the big box and check out my new toys.
flyinfool1 is offline
Reply With Quote
Old 03-19-2015, 04:29 PM
  #5
Terry Holston
My Feedback: (1)

Terry Holston's Avatar

Join Date: Dec 2001
Location: Fort Wayne, IN
Posts: 3,756
Gallery
My Gallery
Models
My Models
Ratings
My Feedback
Default

It's 8:30 PM on the 19th........Is it ready to fly yet????????????????? LOL
Terry Holston is offline
Reply With Quote
Old 03-19-2015, 06:22 PM
  #6
flyinfool1
Thread Starter
My Feedback: (2)

flyinfool1's Avatar

Join Date: Jan 2002
Location: Cudahy, WI
Posts: 831
Gallery
My Gallery
Models
My Models
Ratings
My Feedback
Default

It was foamed into the box, It took me a couple of hours just to get it out of the box.
Sure is bigger that I envisioned.
Will post some pics tomorrow.
flyinfool1 is offline
Reply With Quote
Old 03-20-2015, 08:48 AM
  #7
flyinfool1
Thread Starter
My Feedback: (2)

flyinfool1's Avatar

Join Date: Jan 2002
Location: Cudahy, WI
Posts: 831
Gallery
My Gallery
Models
My Models
Ratings
My Feedback
Default

Here are some pics of the unboxing.





Attached Thumbnails Click image for larger version

Name:	20150319_173238.jpg
Views:	605
Size:	1.49 MB
ID:	2082744   Click image for larger version

Name:	20150319_173623.jpg
Views:	630
Size:	1.76 MB
ID:	2082745   Click image for larger version

Name:	20150319_180421.jpg
Views:	622
Size:	1.49 MB
ID:	2082746   Click image for larger version

Name:	20150319_174201.jpg
Views:	622
Size:	1.42 MB
ID:	2082747   Click image for larger version

Name:	Pulso1.jpg
Views:	621
Size:	25.9 KB
ID:	2082748
flyinfool1 is offline
Reply With Quote
Old 03-17-2017, 07:06 AM
  #8
flyinfool1
Thread Starter
My Feedback: (2)

flyinfool1's Avatar

Join Date: Jan 2002
Location: Cudahy, WI
Posts: 831
Gallery
My Gallery
Models
My Models
Ratings
My Feedback
Default

Well due to medical i$$ues this got put on hold along with everything else in my life. I am hoping that all of that is now behind me and I am getting back to flying again this year. With all the medical crap I have not even flown in the last 3 years other than a park flier a couple of times.

I have started working on this project again, I think I now have everything I need to build this thing up. I am starting to acquire all the stuff needed for ground support.
I cut the hole in the top of the fuse for the canopy access, this was the first time I got to see inside the plane. The layup is white gel cote, light glass cloth, then a heavy layer of kevlar/carbon fiber. Seems very strong. The particular plane that I bought was a "blem" and I got a significant price reduction so it will need a lot of extra TLC to get ready for paint, There were air bubbles in the gel cote.

I have machined the engine mounts that will be needed.
Since I have never played with a pulse jet I will be building up a test bench for it to learn how to work it without burning down the plane.

This will still be a slow build. I have never been a fast builder unless I had a specific deadline to meet. I realized that it has been around 15 years since I built an airplane.
flyinfool1 is offline
Reply With Quote
Old 03-17-2017, 03:18 PM
  #9
LGM Graphix
My Feedback: (22)

LGM Graphix's Avatar

Join Date: Apr 2003
Location: Abbotsford, BC, CANADA
Posts: 5,587
Gallery
My Gallery
Models
My Models
Ratings
My Feedback
Default

Very cool looking project. Where is the super scout available from and what kind of $$$ are they? A ballistic turbine version would be a lot of fun.
LGM Graphix is offline
Reply With Quote
Old 03-18-2017, 06:26 AM
  #10
flyinfool1
Thread Starter
My Feedback: (2)

flyinfool1's Avatar

Join Date: Jan 2002
Location: Cudahy, WI
Posts: 831
Gallery
My Gallery
Models
My Models
Ratings
My Feedback
Default

If for some reason the Pulse jet becomes to much of a hassle, it should be a simple conversion to replace it with a turbine. I was thinking that a K80 would be about right, The pulse jet is rated at about 18 lbs of thrust.
Adding landing gear would be a lot more difficult since there is no internal structure designed for landing gear loads. The mods to meet AMA regs would be harder than adding the turbine.

Although if you are after ballistic, The Viper from the same source is smaller an lighter and much more aerodynamic. It is a lot faster and can be ordered with a depression in the top and mounts for a turbine. I think either one will easily go 199.9 MPH.

Look up "Days of Speed and Thunder" Hubert is the one that makes all of this.

Last edited by flyinfool1; 03-18-2017 at 06:30 AM.
flyinfool1 is offline
Reply With Quote
Old 03-18-2017, 12:17 PM
  #11
i3dm
My Feedback: (51)

Join Date: Jun 2004
Location: Reut,Israel
Posts: 4,211
Gallery
My Gallery
Models
My Models
Ratings
My Feedback
Default

Does Hubert have a website where we can see his kits?
whats the price of these kits?

Last edited by i3dm; 03-18-2017 at 12:21 PM.
i3dm is offline
Reply With Quote
Old 03-18-2017, 12:57 PM
  #12
flyinfool1
Thread Starter
My Feedback: (2)

flyinfool1's Avatar

Join Date: Jan 2002
Location: Cudahy, WI
Posts: 831
Gallery
My Gallery
Models
My Models
Ratings
My Feedback
Default

He does not have a website for his products.
He is the person that runs "Days of Speed and Thunder".
Here is that website, his contact info is on the site.
http://www.pulsotriebwerk.de/home_e.html
I was able to see all of his stuff on Youtube and then did the deal thru email. He is in Germany and we did the deal with email (he does speak enough English) I did call him once on the phone, and payment thru PayPal.
It was 2 years ago that I bought mine and mine was a discounted blemished model, I have no Idea on current pricing.

Last edited by flyinfool1; 03-18-2017 at 01:00 PM.
flyinfool1 is offline
Reply With Quote
Old 03-26-2017, 04:08 PM
  #13
flyinfool1
Thread Starter
My Feedback: (2)

flyinfool1's Avatar

Join Date: Jan 2002
Location: Cudahy, WI
Posts: 831
Gallery
My Gallery
Models
My Models
Ratings
My Feedback
Default

This is the first whole airplane that I am going to paint, just because it is all glass. Monocote does not work well on glass.
The control surfaces are balsa so I plan to cover them with 3/4 oz glass cloth just so that everything will match.
It has been a LONG tome since I have painted anything and I have never painted anything this big. I spent the whole weekend filling and sanding and filling and sanding and filling and sanding................................
And I am no where near done filling and sanding. And this is just filling the holes I can see. There has got to be an easier way....?
flyinfool1 is offline
Reply With Quote
Old 04-12-2017, 06:48 AM
  #14
flyinfool1
Thread Starter
My Feedback: (2)

flyinfool1's Avatar

Join Date: Jan 2002
Location: Cudahy, WI
Posts: 831
Gallery
My Gallery
Models
My Models
Ratings
My Feedback
Default

I did get the control surfaces built this weekend.
The elevons are made from a metric equivalent of close to 5/16 x 1-1/4 trailing edge stock, solid balsa.
I fitted them where they will go to determine the location needed for the control horn. My control horns are mounted with 4 screws. So just diagonally inboard of the screw locations I drilled thru and put in a piece of 1/8 dia hardwood dowel, so that I can crank down on the mounting screws an not just crush the balsa.
I then covered the whole control surface with 3/4 oz glass cloth and epoxy. I have never tried to do something like this so it was a learning experience. The second one did come out better than the first. I have no desire to ever attempt this on a whole airframe.

Next up, I already have the parts cut out for the radio tray and the canopy mounting rails. I plan to mount up the motor so I can move stuff around to get the CG at least close to the correct starting point. Once I get the pulse jet mounted it may be a great opportunity for some more pics for you folks.
flyinfool1 is offline
Reply With Quote
Old 04-23-2017, 01:08 PM
  #15
flyinfool1
Thread Starter
My Feedback: (2)

flyinfool1's Avatar

Join Date: Jan 2002
Location: Cudahy, WI
Posts: 831
Gallery
My Gallery
Models
My Models
Ratings
My Feedback
Default

Well here are a few pics to wet your appetite.

It sure does not look a lot different from when I started, but there is a lot of time wrapped up in it already, most was filling and sanding and the early parts of paint prep.

The pulse jet is just temporarily mounted to get a rough idea on where the CG is headed. It looks like everything needs to be as far forward as it can go and I will still need a lot of lead in the nose. This also means that there is no reason to skimp on any structure up front.
Attached Thumbnails Click image for larger version

Name:	PJ1.jpg
Views:	70
Size:	2.35 MB
ID:	2211345   Click image for larger version

Name:	PJ4.jpg
Views:	67
Size:	2.50 MB
ID:	2211346   Click image for larger version

Name:	PJ5.jpg
Views:	54
Size:	2.45 MB
ID:	2211347   Click image for larger version

Name:	PJ2.jpg
Views:	51
Size:	3.22 MB
ID:	2211348
flyinfool1 is offline
Reply With Quote
Old 04-27-2017, 07:25 AM
  #16
flyinfool1
Thread Starter
My Feedback: (2)

flyinfool1's Avatar

Join Date: Jan 2002
Location: Cudahy, WI
Posts: 831
Gallery
My Gallery
Models
My Models
Ratings
My Feedback
Default

I have decided to add in an extra safety feature. I am going to add a heat sensor that will cut power to the fuel pump in the event of a flame out. Pulse Jets are very sensitive to air bubbles. An unexpected flame out low and at 250 MPH could have my fingers busy and not be able to stop the fuel flow. My plan is to have a K Type thermocouple (same type as most turbines) about half way down the thrust tube of the PJ, if that cools then there was a flame out and it will open a relay to cut power to the pump.
We will see how this works out on the test bench.
In reading the PJ manual again I noted that it can be run on either straight Kero with 5% oil or a 60% kero / 40% gasoline mix with 5% oil added to that mix.. The oil is only to lubricate the gears in the fuel pump.
flyinfool1 is offline
Reply With Quote
Old 05-08-2017, 08:47 AM
  #17
flyinfool1
Thread Starter
My Feedback: (2)

flyinfool1's Avatar

Join Date: Jan 2002
Location: Cudahy, WI
Posts: 831
Gallery
My Gallery
Models
My Models
Ratings
My Feedback
Default

Hmmmmmm
Glue or screws????
I am close to the point of attaching the vertical fins. The instructions say to epoxy them to the airframe.
My concern is that the elevon linkage runs thru the inside of the fins. If I epoxy them on then there is zero access to inspect or service the linkages. The other option is to drill holes thru the wing to epoxy in some hardwood dowels that can be drilled for some screws that will go into the bottom of the fins. I am not sure just how I would get a strong thread into the fin for this attachment. But I do really like the option of access to the control linkages.
The bottom of the fin is 3/8 to 1/2 thick balsa, sanded to match the airfoil of the wing.
For the front screw it will be fairly easy to add some structure and a ply plate with a metal T nut to the inside of the fin. for a rear screw the pushrod runs straight across the balsa fin bottom that is carved out for clearance, a centered screw would hit the pushrod and not really any room to add structure.

Any other ideas?
flyinfool1 is offline
Reply With Quote
Old 05-30-2017, 10:48 AM
  #18
flyinfool1
Thread Starter
My Feedback: (2)

flyinfool1's Avatar

Join Date: Jan 2002
Location: Cudahy, WI
Posts: 831
Gallery
My Gallery
Models
My Models
Ratings
My Feedback
Default

I seem to have run into a bit of a snag in the building process, the snow all melted, weather got nice, and I been outside playing.................
flyinfool1 is offline
Reply With Quote
Old 10-12-2018, 10:47 AM
  #19
flyinfool1
Thread Starter
My Feedback: (2)

flyinfool1's Avatar

Join Date: Jan 2002
Location: Cudahy, WI
Posts: 831
Gallery
My Gallery
Models
My Models
Ratings
My Feedback
Default

Well it has been a while since I even looked at this thing. Medical issues and the associated bills got in the way of everything. I am starting to fiddle with this again. I think I have everything I need to build the actual aircraft. I am now acquiring odds and ends that will be needed to for the support stuff. I am so far astounded at the pile of stuff and cost for the necessary support equipment.

First is the ignition system for starting, I need something that will have a quick release from the spark plug that will fire the plug with a continuous spark. I got an automotive ignition coil and condenser like the old points systems used. Remember those days? I will use a DPDT relay wired as a buzzer to cycle the power to the ignition coil to generate the sparks. That output will be thru 2 long high voltage wires with alligator clips to the plug and ground. I will use a small gel cell 12V battery to power the whole mess with some fuses and switches as required and then find a box to hold it all. I had thought of building a small PC board with a square wave generator to provide the pulses to the coil, but for now that is to much like work. I have this part all designed and have everything but the box to build it in.

The next special piece of support equipment is the air supply for starting.
The pulse jet instructions say I need a mix of air and propane to be blown in to initiate ignition.
I have done a lot of head scratching on this one and watching YouTube videos. What I came up with is to use an 11 gallon air tank that will be filled to 125 PSI with air. from there I will have the airline to a blow gun with a long nozzle. Next to the trigger of the blow gun I will have a start valve for a propane burner. the kind if valve that has a thermocouple to turn off the gas if the fire goes out. these have an override button you push to keep the gas flowing while the thermocouple heats up. Well I will leave off the thermocouple to use it as a push button propane valve. Then I need a hose to a regulator that will allow me to control the flow rate of the propane and a 1 lb propane bottle. I will also need a small air compressor to fill the air tank. I should be able to run the air compressor off of the 2000/4000W inverter in my truck. The cost of this mess of parts is adding up quick.

And in the midsts of these 2 parts of the project, I have been working on the plane little by little. I have got the radio tray all built and installed, and am still forever finding and filling imperfections in the surface of the plane. At some point I will just call enough enough, and just paint it flaws and all. At 250MPH no one will see the flaws. I am terrible at painting anyhow. I am debating hiring a pro to do flames with bright colors on the top and just some contrasting bars on the bottom and then clear the whole thing.

I still have not made up my mind on the vertical fin attachment, I can make a strong case for either option. At this point I am leaning toward gluing them on permanently with a small access hole that will allow me to see and reach the screw that holds the pushrod to the servo arm. This will not be an everyday flyer. A dozen flights a year will be a lot, mostly to not abuse anyone (other pilots or neighbors) with the noise it will make.

I have not even started looking at what to do for a launching system.......$$$$
flyinfool1 is offline
Reply With Quote
Old 10-16-2018, 07:57 AM
  #20
flyinfool1
Thread Starter
My Feedback: (2)

flyinfool1's Avatar

Join Date: Jan 2002
Location: Cudahy, WI
Posts: 831
Gallery
My Gallery
Models
My Models
Ratings
My Feedback
Default

For the heat reflector below the PJ, I got hold of some of the gold foil that NASA uses on satellites to reflect heat. Not cheap but will look really cool, and should get the job done. The aluminum tape would have been a lot cheaper but would not look as pretty.

The propane regulator and gas valve are on the way, I already have a selection of blow guns on hand to pick one from. Once I get these parts I can measure to see what threads the fittings are and then try to find the hoses I will need to make the connections.
flyinfool1 is offline
Reply With Quote
Old 10-22-2018, 07:10 AM
  #21
flyinfool1
Thread Starter
My Feedback: (2)

flyinfool1's Avatar

Join Date: Jan 2002
Location: Cudahy, WI
Posts: 831
Gallery
My Gallery
Models
My Models
Ratings
My Feedback
Default

The propane parts are here and I am now trying to find the fittings to connect them up.
Started to mount electronics and stuff to the radio tray. I have the bubble trap, fuel pump and the ESC for the fuel pup mounted. Those pretty much dictated where the RX will have to go. Then the switch and BEC will go where ever there is room. The battery will be stuffed way up in the nose. The battery will be a 5S NiMh. I will still need the BEC because the factory installed servos are 4.8V and are permanently built into the wing. If I ever have a servo issue I will have to do major surgery to get new servos in there.

I have decided that the fins will be glued on, I added a plywood plate to the inside and cut an inspection hole for the servo linkage. The inspection hole is just big enough to get in and remove the linkage or tighten the screw, should I ever have to. I will add a generous fillet of something to help spread the load out and give a bigger effective glue joint. Was thinking of a mix of epoxy and milled glass and/or micro balloons to make the fillets. I also thought of using 1/4 inch triangle stock for the fillets.

It is in that phase where you work like mad and at the end of the day you step back and see no change because it is all small details that are internal.
flyinfool1 is offline
Reply With Quote
Old 11-05-2018, 06:44 PM
  #22
flyinfool1
Thread Starter
My Feedback: (2)

flyinfool1's Avatar

Join Date: Jan 2002
Location: Cudahy, WI
Posts: 831
Gallery
My Gallery
Models
My Models
Ratings
My Feedback
Default

I got the release mechanism for the launcher built. Of corse it was a lot more work and took a lot longer than I expected


flyinfool1 is offline
Reply With Quote
Old 12-19-2018, 08:09 AM
  #23
flyinfool1
Thread Starter
My Feedback: (2)

flyinfool1's Avatar

Join Date: Jan 2002
Location: Cudahy, WI
Posts: 831
Gallery
My Gallery
Models
My Models
Ratings
My Feedback
Default

Well I took a detour back to the ignition box. I now have the actual circuit all bread boarded up and have started to assemble it into a waterproof case. Of course as I always seem to do I added complexity as I progressed. I have 4 red flashing LEDs to warn that it is powered up. I have added an interlock so that if the case is open the power shuts off. For now I have gone with the original plan of the relay and ignition coil. this setup is giving me about a 3/4 inch long very bright blue nearly continuous spark. when connected to the spark plug I have opened the gap way up and still have a very hot spark that will ignite paper instantly. I am getting close to having it all installed into its water proof case. I will post pics when I finish it. Just waiting for the big brown truck to bring some more parts to mount everything in the case..

I do not know how long the relay will last with this abuse, so I have a spot in the case for a couple of spares.

I have also designed a solid state spark generator and have gotten as far as drawing up the schematic and the printed circuit board layout. I have neither acquired any parts for this version nor done any actual building of it. So far this version just lives on paper.
flyinfool1 is offline
Reply With Quote
Old 12-28-2018, 09:44 AM
  #24
flyinfool1
Thread Starter
My Feedback: (2)

flyinfool1's Avatar

Join Date: Jan 2002
Location: Cudahy, WI
Posts: 831
Gallery
My Gallery
Models
My Models
Ratings
My Feedback
Default

OK as promised her are some pics of the ignition box.

I have now completed the ignition system for the engine. I need a continuous spark to get the fuel to ignite. once the pulse jet is running the flame is self sustaining. this box will stay on the ground and is just for starting. It produces a spark about 3/4 inch long, and has a really hot fire across the electrodes of the spark plug. It is really pretty simple electrically. A 12V battery, A relay wired as a buzzer, which also acts as the points in an old bike, a condenser to try to save the relay contacts a bit, and an automotive ignition coil to step the voltage way up. I also added 4 random flashing LEDs to show that the power is on. I have some "DANGER HIGH VOLTAGE" stickers coming to put by the switch and the output terminals.

Next on the list is the Air supply for starting. This will need a source of compressed air and that will need to be mixed with the correct amount of propane to make a nice combustible mixture to blow into the front of the engine. Once this mix ignites inside of the engine I can then turn on the main fuel flow and it should keep running at that point. As soon as I get all of this ground support stuff designed and built I can do the first test fire of the Pulse Jet engine on a test stand.

There is still a lot of work to do on the aircraft itself, but that is also coming along little by little.




Ignition Box



Spark Jumping a gap.



Spark plug.
flyinfool1 is offline
Reply With Quote
Old 10-20-2019, 05:21 PM
  #25
flyinfool1
Thread Starter
My Feedback: (2)

flyinfool1's Avatar

Join Date: Jan 2002
Location: Cudahy, WI
Posts: 831
Gallery
My Gallery
Models
My Models
Ratings
My Feedback
Default

Well this ended up on hold for a while again with more health junk. But I am back at it again. The construction phase is pretty much done, and I just splashed on the first coat of primer. The first coat is just a light dusting of black primer. al other coats of primer will be bright white. The black is just so I can tell when almost all of the white primer has been sanded off. This is an aircraft where weight matters, so each coat of the white has to be sanded off almost entirely just leaving what is needed to fill imperfections. Right now it really looks like a stealth missile in all flat black primer. It is nearly invisible in the pics I tried to take.

I still have not decided on a paint scheme other than it will be very bright colors for visibility.
flyinfool1 is offline
Reply With Quote

Thread Tools
Search this Thread

Contact Us Archive Advertising Cookie Policy Privacy Statement Terms of Service
