Hey Warbird guys
I'm currently involved in 2 projects. One is my old mans scratch built F-4U Corsair in 1/6 scale. The other is a SIST FW190 i am considering for myself.
The problem i am facing is lacking accurate drawings to draw up everything i need (Cockpit interior on both incl cross sections to make a 3d model of the hull, gear and guns on the FW190).
Either i find the usual low resolution 5-views and cross sections from the usual sites, or i find offers to buy entire CDs with 23000 factory drawings priced in the 3-digit range, from which i will find only 2-3 pages useable. Alternatively you find purchaseable prints in large scale....but then i need to find a scanning service.
Maybe someone has stumbled across something that he may be willing to share with me? Like i said im not looking for 23000 drawings of each screw used. Good large accurate cross sections (especially with multiple cuts in the cockpit sections) and some internals as shown below would be wonderful. Those are the Bentley drawings that can only be obtained as large prints....sadly i have yet to find them digitally in good scale.
If you dont want to post here let me know via PM

Many thanks!

Cheers Hank


Last edited by Miniflyer; 07-03-2019 at 01:39 AM. Reason: More info added
Old 07-03-2019, 04:16 AM
  #2
warbirdcharly

warbirdcharly's Avatar

Join Date: Feb 2015
Posts: 137
Likes: 0
Received 1 Like on 1 Post
Default



i have these book, the language is polski? i dont can read it, only look at the good fotos
Old 07-03-2019, 04:17 AM
  #3
warbirdcharly

warbirdcharly's Avatar

Join Date: Feb 2015
Posts: 137
Likes: 0
Received 1 Like on 1 Post
Default



only 1 of 260 pages
Old 07-03-2019, 05:56 AM
  #4
Miniflyer
Thread Starter

Join Date: Dec 2004
Location: Neuburg, GERMANY
Posts: 1,062
Likes: 0
Received 12 Likes on 8 Posts
Default

That looks good. Can you scan it so it is free of distortions and perspectice? Would very much appreciate it
Old 07-07-2019, 04:00 PM
  #5
invertmast
My Feedback: (23)

invertmast's Avatar

Join Date: Dec 2003
Location: Capon Bridge, WV
Posts: 8,103
Received 97 Likes on 64 Posts
Default

The FW190 CD on ebay is a good investment for what you are looking for.

Outside of that, the AL Bentley drawings are the next best.
Old 07-10-2019, 06:21 AM
  #6
Miniflyer
Thread Starter

Join Date: Dec 2004
Location: Neuburg, GERMANY
Posts: 1,062
Likes: 0
Received 12 Likes on 8 Posts
Default

Originally Posted by invertmast View Post
The FW190 CD on ebay is a good investment for what you are looking for.

Outside of that, the AL Bentley drawings are the next best.
Thanks. There are various offerings on ebay and the web. There are some reviews of them on the Warbirdforum, and most of the guys were highly disappointed by what they got. Id buy the bentley drawings, but they are only available from Albert as hard copies. This will set me back much more than i wanted, considering i only need 2-3 sections.
If you have a source that you consider worthy please do share
Old 07-10-2019, 10:18 AM
  #7
invertmast
My Feedback: (23)

invertmast's Avatar

Join Date: Dec 2003
Location: Capon Bridge, WV
Posts: 8,103
Received 97 Likes on 64 Posts
Default

Originally Posted by Miniflyer View Post
Thanks. There are various offerings on ebay and the web. There are some reviews of them on the Warbirdforum, and most of the guys were highly disappointed by what they got. Id buy the bentley drawings, but they are only available from Albert as hard copies. This will set me back much more than i wanted, considering i only need 2-3 sections.
If you have a source that you consider worthy please do share

buy them from bentley. Otherwise if we stop supporting these people they will stop doing it.

the CD’s have far more “filler” of stuff you’ll never use for a model, but they also have multiple sheets of engineering cross sections for the fuselage, wing fillets, wing, tail, pretty much everything needed to make a 100% accurate Fw190
Old 07-10-2022, 05:57 PM
  #8
Halcyon66

Join Date: Aug 2016
Location: Gone Yachting
Posts: 451
Received 45 Likes on 35 Posts
Default

Was looking for something else and came across this thread.

These may help.

Focke Wolf Fw 190A Drawings english text

Focke Wulf Fw-190 A-8 Aircraft Blueprints - Download - Aircraft Reports - Aircraft Manuals - Aircraft Helicopter Engines Propellers Blueprints Publications








Have more on another drive will have a look around.

Regards,
Old 07-10-2022, 06:06 PM
  #9
Halcyon66

Join Date: Aug 2016
Location: Gone Yachting
Posts: 451
Received 45 Likes on 35 Posts
Default

F-4u





Again have more material yet seems to be a issue uploading it.

Regards,
