Red face my next generation roll center sway bar for any scale vehicle

2nd version generation 4

if you raize one side of lower suspension arm it of course lift the other side

but at the same time and or any time and or before that

the ball put preasure on the oposite tire increase grip to drive better at any time left right front rear



1st version generation 3 i dezign that took to much room to many part az double bearing



here iz the original generation - prototype i made a few yearz ago



i would say say

generation 0 iz no sway bar
generation 1 iz a team associated tc5 sway bar no bearing
generation 2 iz a team xray t4 2018 sway bar with bearing
generation - prototype see my prototype
generation 3 prototype see my prototype
generation 4 my center ball thought created 2018 may 13 sunday 02:00 p.m
generation 5 feature my rear generation 4 and or front end connect to front knuckle steering arm and turn when knuckle turn
to compress inside front suspension and decompress out side front suspension that angle main lower chassis plate for
center gravity toward turn instead of the oposite way natural with a example 1:10 scale electric buggy that main lower
chassis plate tip to out side side of car if you turn left chassis top right which iz roll center anti

i make a lot of new generation part see link below
